• Stainless Steel

    Material

  • 1/2"-6"

    Size

  • BSPT/NPT

    Thread

Stainless Steel Camlock Couplings

Straight Socket Connector

The LT-23B Straight Socket Connector offers robust performance for various industries with its superior corrosion resistance and precision casting technology.

  • Corrosion Resistant
  • Leak-Proof Design
  • Quick Connection
    • OEM Custom
    • Fast And Safe Logistics

    Straight Socket Connector

    The LT-23B Straight Socket Connector is engineered for durability and efficiency, making it ideal for applications in fuel and oil transfer, agriculture, and food processing. Manufactured using advanced Silica Sol Precision Casting Technology, this connector ensures exceptional tensile strength and elongation, allowing it to withstand high pressure and varying temperatures. Its corrosion-resistant stainless steel construction ensures longevity and reliability, while the various threading options make it versatile for different installations. Whether for aviation fueling or gas distribution, this connector promises secure performance.

    Features

    High Tensile Strength

    With a tensile strength of 485Mpa, this connector can handle significant stress, making it suitable for high-pressure applications.

    Temperature Resilience

    Operates effectively in a temperature range of -22°F to +248°F, ensuring versatility across diverse environments.

    Precision Casting

    Utilizes advanced Silica Sol Precision Casting Technology for enhanced dimensional accuracy and performance reliability.

    Multiple Thread Options

    Compatible with various threading standards including BSPT, NPT, and DIN, allowing for seamless integration into existing systems.

    Applications

    Fuel & Oil

    Camlock couplings are indispensable in the fuel and oil industry, providing reliable and leak-proof connections for transferring petroleum products. Their quick connect/disconnect capability enhances safety and efficiency during loading and unloading processes.

    Agriculture

    Food and Beverages

    Gas

    Specs

    1/2"-6"

    Product Specifications

    Product CodeLT-23B
    Size1/2"-6"
    TechnologySilica Sol Precision Casting Technology
    Physical PropertyTensile strength: 485Mpa, Yield strength > 205Mpa, Elongation: 35%
    Material We Can DoStainless steel 304/316/CF8/CF8M/1.4308/1.4417
    ThreadBS21 (BSPT&BSPP), ANSI/ASME B1.20.1 (NPT), DIN2999(R/RP), JIS B O203/2(PT), KS BO221/2(PT), etc.
    Temperature-22°F to +248°F(-30℃ to +120°C)
    SurfacePickling and Peeling
    ModelC-002
    ShapeEqual

    Logistics and Certifications

    CertificateISO 9001:2015,IS014001:2015, CE, ROHS, KC, etc..
    PackagePVC bag for each piece.Cartons with pallet/out pallet/wooden boxes
    PortNingbo/Shanghai, China Or other port on request.
    SampleOffer free samples and freight collected
    Delivery DetailAccording to the quantities and specifications of each orderA complete stock to provide fast deliveries for small orders.Normal delivery times is from 30 to 45 days after receiving the deposit
    Generic ApplicationsFuel & Oil, Agriculture, Food and Beverages, Gas
    Get Instant Quote

    Support

    More Support

    Installation Guide

    For installation, begin by ensuring that the surfaces of the connecting pipes are clean and free of debris. Align the threads of the LT-23B Straight Socket Connector with the corresponding pipe threads. Carefully hand-tighten to avoid cross-threading, then use a wrench for a secure fit, ensuring not to over-tighten. After installation, check for leaks by applying a suitable pressure test. Always follow safety protocols and consult the installation manual for further guidance if needed.

    After-Sales Maintenance

    FAQs

    Looking for answers about Straight Socket Connector? Visit our FAQ section for detailed information and expert insights.

    Contact Us
    • What materials are available for this connector?
      The LT-23B Straight Socket Connector is available in ASTM A351 CF8 (stainless steel 304) and ASTM A351M CF8M (stainless steel 316), ensuring durability and corrosion resistance.
    • Can I use this connector for gas applications?
      Yes, this connector is suitable for various gas applications, including natural gas distribution and LPG transfer, thanks to its leak-proof design and robust construction.
    • Is a sample available for testing?
      We offer free samples of the LT-23B Straight Socket Connector. However, freight charges will be collected, allowing you to evaluate our product before making a larger commitment.
    • What are the delivery times for orders?
      Delivery times typically range from 30 to 45 days after receipt of the deposit, depending on the quantities and specifications of your order. We maintain a complete stock for fast deliveries on smaller orders.
    • What certifications does this product have?
      The LT-23B Straight Socket Connector is certified to ISO 9001:2015, ISO 14001:2015, CE, ROHS, and KC standards, ensuring compliance with international quality and environmental regulations.
