• Stainless Steel

    Material

  • 1/2" 3/4" 1"

    Size

  • BSPT/BSPP/NPT

    Thread

Metal Pipe Fittings

Three-Dimensional Cross F-F-F-F

The Three-Dimensional Cross F-F-F-F is a high-strength pipe fitting crafted using advanced silica sol precision casting for superior durability. Ideal for various applications.

  • High Strength
  • Corrosion Resistant
  • Wide Temperature Range
    • OEM Custom
    • Fast And Safe Logistics

    Three-Dimensional Cross F-F-F-F

    The Three-Dimensional Cross F-F-F-F is engineered to meet the highest standards of performance and safety. Utilizing cutting-edge silica sol precision casting technology, this pipe fitting guarantees remarkable tensile strength and exceptional yield strength, making it ideal for systems involving high-pressure and corrosive mediums. With a wide temperature tolerance ranging from -76°F to +572°F, it operates efficiently in extreme conditions. The product is designed for easy installation and maintenance, ensuring a reliable connection across various industries including fuel and oil, agriculture, and food processing.

    Features

    High Pressure Resistance

    Designed to withstand high pressure, this fitting ensures secure connections in demanding hydraulic and fluid delivery systems.

    Corrosion Resistant

    Manufactured from premium stainless steel 304/316, it offers exceptional resistance to corrosion in harsh environments.

    Easy Installation

    This product's design allows for straightforward installation, reducing downtime and ensuring quick setup for any project.

    Wide Compatibility

    Compatible with various threading standards, including BSPT, NPT, and JIS, making it versatile for multiple applications.

    Applications

    Fuel & Oil

    Camlock couplings are indispensable in the fuel and oil industry, providing reliable and leak-proof connections for transferring petroleum products. Their quick connect/disconnect capability enhances safety and efficiency during loading and unloading processes.

    Agriculture

    Food and Beverages

    Gas

    Specs

    1/2"3/4"1"

    Product Specifications

    Product CodeLT-08D
    Size1/2"3/4"1"
    TechnologySilica Sol Precision Casting Technology
    Physical PropertyTensile strength: 485Mpa, Yield strength > 205Mpa, Elongation: 35%
    Material We Can DoStainless steel 304/316/CF8/CF8M/1.4308/1.4446
    ThreadBS21 (BSPT&BSPP), ANSI/ASME B1.20.1 (NPT), DIN2999(R/RP), JIS B O203/2(PT), KS BO221/2(PT), etc.
    Temperature-76°F to +572°F(-60℃ to +300°C)
    SurfacePickling and Peeling
    ModelP-039
    ShapeEqual

    Logistics and Certifications

    CertificateISO 9001:2015,IS014001:2015, CE, ROHS, KC, etc..
    PackagePVC bag for each piece.Cartons with pallet/out pallet/wooden boxes
    PortNingbo/Shanghai, China Or other port on request.
    SampleOffer free samples and freight collected
    Delivery DetailAccording to the quantities and specifications of each orderA complete stock to provide fast deliveries for small orders.Normal delivery times is from 30 to 45 days after receiving the deposit
    Generic ApplicationsFuel & Oil, Agriculture, Food and Beverages, Gas
    Get Instant Quote

    Support

    More Support

    Installation Guide

    To install the Three-Dimensional Cross F-F-F-F, ensure that the pipe ends are clean and free from debris. Align the fitting with the pipes as per the threading standards. Hand-tighten the fitting initially to avoid cross-threading, followed by a wrench for a secure fit. Check for leaks after installation by applying pressure to the system. It is advisable to use appropriate sealing materials for enhanced safety and reliability. Always follow local codes and regulations during installation.

    After-Sales Maintenance

    FAQs

    Looking for answers about Three-Dimensional Cross F-F-F-F? Visit our FAQ section for detailed information and expert insights.

    Contact Us
    • What materials are used for this product?
      The Three-Dimensional Cross F-F-F-F is available in stainless steel 304 and 316, ensuring strength and corrosion resistance for various applications.
    • What is the temperature range?
      This fitting can operate efficiently within a temperature range of -76°F to +572°F (-60°C to +300°C), making it suitable for extreme conditions.
    • Is a warranty provided?
      Yes, we offer a warranty for the Three-Dimensional Cross F-F-F-F, ensuring quality and performance. Please refer to the warranty policy for details.
    • Can I get a sample before purchase?
      Absolutely! We provide free samples of the Three-Dimensional Cross F-F-F-F. Shipping costs will be collected from the customer upon delivery.
    • What is the delivery time?
      Normal delivery times for the Three-Dimensional Cross F-F-F-F are between 30 to 45 days after receiving the deposit, depending on order quantities and specifications.
