• Stainless Steel

    Material

  • 1/4"-2"

    Size

  • BS21/ANSI NPT

    Thread

Metal Pipe Fittings

TEE F-M-F

The TEE F-M-F is a high-quality pipe fitting designed for various applications, ensuring safety and reliability in fluid transport systems.

  • High Strength
  • Corrosion Resistant
  • Wide Temperature Range
    • OEM Custom
    • Fast And Safe Logistics

    TEE F-M-F

    The TEE F-M-F is crafted using Silica Sol Precision Casting Technology, ensuring superior strength and durability. With a tensile strength of 485Mpa and yield strength greater than 205Mpa, this fitting is ideal for high-pressure applications. It is available in stainless steel 304 and 316, making it resistant to corrosion and suitable for challenging environments. The TEE F-M-F design features a pickled and peeled surface for enhanced performance. Its versatile size range from 1/4" to 2" makes it adaptable for various industries, including oil, gas, agriculture, and food processing.

    Features

    Precision Casting

    Utilizes advanced Silica Sol Precision Casting Technology for precise dimensions and superior strength.

    High-Temperature Resistance

    Capable of withstanding temperatures from -76°F to +572°F, suitable for diverse fluid systems.

    Corrosion Resistance

    Manufactured from stainless steel materials that resist corrosion in harsh environments.

    Easy Installation

    Designed for quick and hassle-free installation, reducing downtime in operational systems.

    Applications

    Fuel & Oil

    Camlock couplings are indispensable in the fuel and oil industry, providing reliable and leak-proof connections for transferring petroleum products. Their quick connect/disconnect capability enhances safety and efficiency during loading and unloading processes.

    Agriculture

    Food and Beverages

    Gas

    Specs

    1/4"-2"

    Product Specifications

    Product CodeLT-02H
    Size1/4"-2"
    TechnologySilica Sol Precision Casting Technology
    Physical PropertyTensile strength: 485Mpa, Yield strength > 205Mpa, Elongation: 35%
    Material We Can DoStainless steel 304/316/CF8/CF8M/1.4308/1.4419
    ThreadBS21 (BSPT&BSPP), ANSI/ASME B1.20.1 (NPT), DIN2999(R/RP), JIS B O203/2(PT), KS BO221/2(PT), etc.
    Temperature-76°F to +572°F(-60℃ to +300°C)
    SurfacePickling and Peeling
    ModelP-012
    ShapeEqual

    Logistics and Certifications

    CertificateISO 9001:2015,IS014001:2015, CE, ROHS, KC, etc..
    PackagePVC bag for each piece.Cartons with pallet/out pallet/wooden boxes
    PortNingbo/Shanghai, China Or other port on request.
    SampleOffer free samples and freight collected
    Delivery DetailAccording to the quantities and specifications of each orderA complete stock to provide fast deliveries for small orders.Normal delivery times is from 30 to 45 days after receiving the deposit
    Generic ApplicationsFuel & Oil, Agriculture, Food and Beverages, Gas
    Get Instant Quote

    Support

    More Support

    Installation Guide

    To install the TEE F-M-F, first ensure that the connecting pipes are clean and free from debris. Align the fitting with the pipe ends and apply appropriate thread sealant to prevent leaks. Hand-tighten the fitting first, then use a wrench to secure it firmly, being careful not to over-tighten which can damage the fitting. After installation, conduct a pressure test to ensure there are no leaks before putting the system into full operation.

    After-Sales Maintenance

    FAQs

    Looking for answers about TEE F-M-F? Visit our FAQ section for detailed information and expert insights.

    Contact Us
    • What is the maximum pressure rating?
      The TEE F-M-F is designed to handle high-pressure applications, but specific pressure ratings depend on the diameter and material used. Always refer to the manufacturer's specifications for detailed ratings.
    • Can I use this fitting for gas applications?
      Yes, the TEE F-M-F is suitable for gas applications, including natural gas and propane, making it ideal for both commercial and residential use.
    • What materials are available?
      This fitting is available in stainless steel 304 and 316, providing options for different corrosion resistance levels depending on your application needs.
    • Is a sample available before purchase?
      Yes, we offer free samples of the TEE F-M-F, with freight charges collected. This allows you to evaluate the product before making a larger order.
    • What certifications does this product have?
      The TEE F-M-F is certified with ISO 9001:2015, IS014001:2015, CE, ROHS, and KC, ensuring it meets international quality and safety standards.
