• Stainless Steel

    Material

  • 1/4"-1/8" 1/2"-1/4" 1"-3/8" 11/4"-1" 2"-1/2" 21/2"-1/2" 21/2"-11/2" 4"-3"

    Size

  • BS21/ANSI/ASME/DIN

    Thread

Metal Pipe Fittings

Reducing Elbow F-F

The Reducing Elbow F-F is a high-strength pipe fitting designed for various applications, ensuring durability and corrosion resistance in demanding environments.

  • High Strength
  • Corrosion Resistant
  • Wide Temperature Range
    • OEM Custom
    • Fast And Safe Logistics

    Reducing Elbow F-F

    Our Reducing Elbow F-F model is engineered using advanced Silica Sol Precision Casting Technology, ensuring exceptional quality and performance. With a tensile strength of 485MPa and a yield strength exceeding 205MPa, this fitting is designed for high-pressure fluid delivery systems and corrosive mediums. Suitable for temperatures ranging from -76°F to +572°F, it offers versatile applications in fuel, oil, and hydraulic systems. The product is certified with ISO 9001:2015 and CE, assuring compliance with international standards for safety and reliability.

    Features

    High Strength

    Built to withstand high pressures, ensuring safety and durability in demanding applications.

    Corrosion Resistant

    Manufactured from stainless steel, providing excellent resistance to corrosive environments.

    Easy Installation

    Designed for straightforward installation, helping to minimize downtime and labor costs.

    Wide Temperature Range

    Operates effectively in extreme temperatures, from -76°F to +572°F, for diverse applications.

    Applications

    Fuel & Oil

    Camlock couplings are indispensable in the fuel and oil industry, providing reliable and leak-proof connections for transferring petroleum products. Their quick connect/disconnect capability enhances safety and efficiency during loading and unloading processes.

    Agriculture

    Food and Beverages

    Gas

    Specs

    1/4"-1/8"

    Product Specifications

    Product CodeLT-01B
    Size1/4"-1/8"
    TechnologySilica Sol Precision Casting Technology
    Physical PropertyTensile strength: 485Mpa, Yield strength > 205Mpa, Elongation: 35%
    Material We Can DoStainless steel 304/316/CF8/CF8M/1.4308/1.4409
    ThreadBS21 (BSPT&BSPP), ANSI/ASME B1.20.1 (NPT), DIN2999(R/RP), JIS B O203/2(PT), KS BO221/2(PT), etc.
    Temperature-76°F to +572°F(-60℃ to +300°C)
    SurfacePickling and Peeling
    ModelP-002
    ShapeEqual

    Logistics and Certifications

    CertificateISO 9001:2015,IS014001:2015, CE, ROHS, KC, etc..
    PackagePVC bag for each piece.Cartons with pallet/out pallet/wooden boxes
    PortNingbo/Shanghai, China Or other port on request.
    SampleOffer free samples and freight collected
    Delivery DetailAccording to the quantities and specifications of each orderA complete stock to provide fast deliveries for small orders.Normal delivery times is from 30 to 45 days after receiving the deposit
    Generic ApplicationsFuel & Oil, Agriculture, Food and Beverages, Gas
    Get Instant Quote

    Support

    More Support

    Installation Guide

    To install the Reducing Elbow F-F, ensure all surfaces are clean and free of debris. Align the fitting with the pipes, ensuring correct orientation. Use appropriate thread sealant or Teflon tape on threaded connections to ensure a tight seal. Hand-tighten connections and then use a wrench to secure them without over-tightening to avoid damage. Check for leaks after installation by pressurizing the system gradually.

    After-Sales Maintenance

    FAQs

    Looking for answers about Reducing Elbow F-F? Visit our FAQ section for detailed information and expert insights.

    Contact Us
    • What materials are used in this fitting?
      The Reducing Elbow F-F is available in ASTM A351 CF8 (stainless steel 304) and ASTM A351M CF8M (stainless steel 316), providing excellent corrosion resistance and strength.
    • What are the temperature limits?
      This fitting can operate effectively in temperatures ranging from -76°F to +572°F (-60°C to +300°C), making it suitable for various demanding applications.
    • How is this product packaged?
      Each Reducing Elbow F-F is individually packed in a PVC bag, with additional packing options available in cartons with pallets or wooden boxes for safe transport.
    • Can I get a sample before purchase?
      Yes, we offer free samples of the Reducing Elbow F-F. The freight cost will be collected at the time of shipping the sample to your location.
    • What certifications does this product have?
      Our Reducing Elbow F-F is certified with ISO 9001:2015, ISO 14001:2015, CE, ROHS, and KC, ensuring compliance with international quality and safety standards.
