Coalescing Pneumatic Air Filter H-002

Fiberglass, Galvanized steel

Material

"1/2" - "3"

Size

NPT/BSPT

Thread

Valves and Filters

Coalescing Pneumatic Air Filter H-002

Coalescing pneumatic air filters are precision filtration devices specifically designed for compressed air systems. They effectively remove oil mist, moisture, and fine particles from compressed air, delivering clean air that meets safety standards. This equipment is widely used in industrial sectors with extremely high air quality requirements.

Coalescing Pneumatic Air Filter H-002

Coalescing pneumatic air filters utilize the principle of coalescence to effectively separate and filter minute oil mist, moisture, and solid particles from compressed air, ensuring clean air enters the pneumatic system. Employing multi-layer glass fiber filter media, they capture oil aerosols, moisture, and submicron-sized solid particles. Subsequently, the filter element’s coalescing action aggregates minute droplets into dischargeable sizes, achieving reliable separation. This coalescing air filter assembly protects pneumatic components, extends system lifespan, and enhances production efficiency.

The coalescing pneumatic air filter features a galvanized steel housing for mechanical protection and corrosion resistance, making it suitable for harsh industrial environments. Its low-pressure drop design helps reduce energy consumption and improve system efficiency. The replaceable cartridge design minimizes downtime associated with component replacement, further enhancing product performance. The H-002 serves as a filtration system component meeting ISO 8573 compressed air standards for the food, pharmaceutical, and electronics manufacturing industries.

Features

High-Precision Filtration

Utilizes multi-layer filtration media to capture particles as small as 0.01 microns, effectively removing oil mist and moisture from the air to deliver clean air meeting specifications.

Low Pressure Drop Design

Optimized filter elements and internal flow channels minimize pressure drop while maintaining high filtration precision, reducing energy consumption and enhancing system efficiency.

Stable Performance

Utilizes coalescence principles to aggregate oil and water droplets into larger particles for removal, ensuring sustained filtration stability without degradation due to saturation.

Robust Construction

The housing is crafted from high-strength metal, capable of withstanding high-pressure environments and featuring corrosion resistance, making it suitable for long-term operation in harsh conditions.

Applications

Food & Beverage

The coalescing pneumatic air filter delivers oil-free compressed air for filling, spraying and pneumatic controls to protect product safety.

Pharmaceutical & Labs

A coalescing air filter ensures sterile-grade compressed air is available for instruments and clean processes.

General Manufacturing

In manufacturing, a compressed air filter protects the valves, cylinders and air tools, hence reducing maintenance and extending service life. It can also be used in electronics manufacturing to remove oil aerosols and moisture that can damage sensitive components.

Coating & Painting

The oil mist filter can be used for coatings and paintings to prevent oil and water spots on finishes, improving surface quality and yield.

Specs

Product Specifications

Size Range	“1/2” – “3”
Materials	Fiberglass, galvanized steel
Thread Type	NPT/BSPT
Temperature Range	-20°C to 100°C
Maximum Pressure	210 bar

Logistics and Certifications

Certificate	ISO 9001:2015,IS014001:2015, CE, ROHS, KC, etc..
Package	PVC bag for each piece.Cartons with pallet/out pallet/wooden boxes
Port	Ningbo/Shanghai, China Or other port on request.
Sample	Offer free samples and freight collected
Delivery Detail	According to the quantities and specifications of each orderA complete stock to provide fast deliveries for small orders.Normal delivery times is from 30 to 45 days after receiving the deposit
Generic Applications	Oil and Gas, Chemical, Food and Beverage, Agricultural Irrigation

Support

More About Us

Installation Guide

When installing the H-002 model coalescing pneumatic air filter, position it downstream of the aftercooler and pre-filter, ensuring the flow arrow aligns with the airflow direction. Shut off the pipeline and relieve pressure before installation. Use the correct thread sealant and tighten to the recommended torque. Install the coalescing air filter vertically whenever possible, allowing clearance for cartridge removal. After slowly pressurizing and purging trapped air, inspect for leaks and continuously monitor differential pressure during initial operation.

After-Sales Maintenance

At Procamlock, we are committed to ensuring every coalescing pneumatic air filter delivers consistent performance and extended service life. Our after-sales team provides guidance on filter element replacement, best practices for compressed air filtration, and troubleshooting assistance for any technical issues. We also offer access to genuine spare parts to keep your filtration system operating efficiently. Whether you need quick maintenance tips or detailed upkeep advice, our support team is dedicated to helping you maintain optimal performance of your coalescing air filters long after purchase.

FAQs

Looking for answers about Coalescing Pneumatic Air Filter? Visit our FAQ section for detailed information and expert insights.

What is the filtration precision of the Coalescing Pneumatic Air Filter?

It can filter out particles as small as 0.01 microns and larger, meeting ISO high-grade clean air standards, with a filtration efficiency of up to 99.9%.

How often does the filter cartridge need to be replaced?

We generally recommend replacing the filter cartridge every 3-6 months, with the specific frequency depending on the usage environment and air pollution levels.

Can it be used in high-pressure systems?

Yes, our Coalescing Pneumatic Air Filter is made from high-strength materials and can withstand a maximum working pressure of 210 bar, with specifics depending on the material and model.

Can the Coalescing Pneumatic Air Filter be used in combination with other filters?

Yes, it is typically used in combination with pre-filters and activated carbon filters to form a multi-stage air purification system.

What is the temperature range for this product?

The Coalescing Pneumatic Air Filter can operate within a temperature range of -20°C to 100°C while maintaining stable performance.
