2PC Ball Valve M-M

Stainless Steel

Material

1/4"-2"

Size

BSPT/BSPP/NPT

Thread

Valves and Filters

The LT-52F 2PC Ball Valve M-M delivers precision control and robust performance in various applications, ensuring reliability in challenging environments.

2PC Ball Valve M-M

Designed for versatility and durability, the LT-52F 2PC Ball Valve M-M is ideal for a wide range of applications including subsea oil platforms and LNG systems. Utilizing Silica Sol Precision Casting Technology, this valve offers exceptional tensile and yield strength, making it resistant to high temperatures and pressures. With its corrosion-resistant stainless steel construction, it ensures long-lasting performance in harsh environments. The valve’s reliable sealing mechanism provides precise flow control, making it a top choice for industries requiring stringent safety and operational standards.

Features

High Temperature Resistance

The valve operates effectively in temperatures ranging from -22°F to +248°F, making it suitable for extreme conditions.

ISO Certified

Manufactured under stringent ISO 9001:2015 and ISO 14001:2015 guidelines, ensuring high-quality and reliable performance.

Wide Application Range

Applicable in sectors from agriculture to nuclear power, providing functionality across diverse industries.

Easy Maintenance

Designed for quick installation and maintenance, minimizing downtime and enhancing operational efficiency.

Applications

Fuel & Oil

Camlock couplings are indispensable in the fuel and oil industry, providing reliable and leak-proof connections for transferring petroleum products. Their quick connect/disconnect capability enhances safety and efficiency during loading and unloading processes.

Agriculture

In agriculture, camlock couplings are essential for irrigation systems, chemical spraying, and transferring fertilizers. They enable quick and secure hose connections, allowing farmers to change equipment swiftly and improve operational efficiency.

Food and Beverages

Camlock couplings made from food-grade materials are vital in the food and beverage industry. They ensure the hygienic transfer of consumable liquids like juices, dairy products, and syrups, adhering to strict sanitary standards to prevent contamination.

Gas

In the gas industry, camlock couplings provide safe and efficient connections for transferring gases such as LPG and natural gas. Their robust construction ensures a secure seal, minimizing the risk of leaks and enhancing safety in gas handling applications.

Specs

Product Specifications

Product Code	LT-52F
Technology	Silica Sol Precision Casting Technology
Physical Property	Tensile strength: 485Mpa, Yield strength > 205Mpa, Elongation: 35%
Material We Can Do	Stainless steel 304/316/CF8/CF8M/1.4308/1.4415
Thread	BS21 (BSPT&BSPP), ANSI/ASME B1.20.1 (NPT), DIN2999(R/RP), JIS B O203/2(PT), KS BO221/2(PT), etc.
Temperature (Static State)	-22°F to +248°F（-30℃ to +120°C）
Surface	Pickling and Peeling
Model	V-008
Shape	Equal

Logistics and Certifications

Certificate	ISO 9001:2015,IS014001:2015, CE, ROHS, KC, etc..
Package	PVC bag for each piece.Cartons with pallet/out pallet/wooden boxes
Port	Ningbo/Shanghai, China Or other port on request.
Sample	Offer free samples and freight collected
Delivery Detail	According to the quantities and specifications of each orderA complete stock to provide fast deliveries for small orders.Normal delivery times is from 30 to 45 days after receiving the deposit
Generic Applications	Oil and Gas, Chemical, Food and Beverage, Agricultural Irrigation

Support

More About Us

Installation Guide

To install the LT-52F 2PC Ball Valve M-M, ensure that the pipeline is free of debris and pressure is relieved. Align the valve with the piping system and tighten the threads according to the specifications of your chosen thread type (BSPT/BSPP or NPT). Avoid over-tightening to prevent damage. Once secured, ensure proper sealing by checking for leaks during the initial pressure test. Follow safety protocols throughout the installation process.

After-Sales Maintenance

At SSABP, we're proud to deliver high-quality camlock couplings. To ensure you get optimal performance and longevity from our products, we offer comprehensive after-sales maintenance services. Our team is ready to assist with any technical queries, provide maintenance tips, or offer troubleshooting advice. We also supply replacement parts and servicing options to help maintain the durability of your camlock products. Your satisfaction is our commitment, and our support team is always here to keep your operations running smoothly long after your purchase.

FAQs

Looking for answers about 2PC Ball Valve M-M? Visit our FAQ section for detailed information and expert insights.

What sizes are available for this valve?

The LT-52F 2PC Ball Valve M-M is available in sizes ranging from 1/4″ to 2″, accommodating various piping needs and applications.

What materials are used for this valve?

This valve is made from high-quality stainless steel materials including ASTM A351 CF8 (304) and ASTM A351M CF8M (316), ensuring durability and resistance.

Can this valve handle high pressure?

Yes, the LT-52F valve is designed to handle high pressure, with a yield strength greater than 205Mpa, making it suitable for demanding applications.

Is a warranty provided for this product?

Yes, the LT-52F 2PC Ball Valve M-M comes with a manufacturer warranty. Please check with your supplier for specific warranty details and terms.

Are free samples available?

Absolutely! We offer free samples of the LT-52F valve, with freight collected. This allows you to evaluate the product before making a larger order.
